Crane parts service
Steel plants, power stations ships and garbage treatment plant with various cranes, such as, tower cranes, ship cranes, ship unloaders traveling cranes, etc.
Description
Technical Data
| Volume
(m3) |
Motor 40%ED
(kw) |
Crane SWL
(t) |
Grab Weight
(kg) |
Dimension(mm) | |||
| A | B | C | D | ||||
| 0.5 | 7.3 | 2.5 | 945 | 1875 | 1525 | 1480 | 2290 |
| 1 | 7.3 | 3 | 1490 | 2020 | 1770 | 1600 | 2505 |
| 2 | 10 | 5 | 1540 | 2080 | 1790 | 1700 | 2630 |
| 2.5 | 10 | 6.3 | 2825 | 2660 | 2200 | 2350 | 3465 |
| 3 | 14.5 | 10 | 3040 | 2860 | 2240 | 2470 | 3850 |
Details
| # | Details we Kinocranes cares to provide reliable function and long service life |
| 1. | Hydraulic unit equipped with self-regulated piston variable flow pump |
| 2. | Complete load through maximum penetration force applied with special designed profile jaws |
| 3. | Full protected hydraulic cylinders |
| 4. | Structure validated by finite elements analysis |
| 5. | Special penetration teeth built in wear resistant manganese steel |
Advantages
| # | Key Parts | Advantages |
| 1. | Robust grab structure | S355 J2G3 rolled steel |
| 2. | Hydraulic Oil tank | Tightly enclosed and protected from environment |
| 3. | Design & Fabrication | FEM standard 1001/98 |
| 4. | Function | Reduced height, multi-stable, can work at any angle (± 60°). |
Product Application
Kinocranes know the hazard and challenge of metals production industry. Kinocranes design crane for steel industry with safety first, robust design, high performance advantages.
The entire garbage crane is designed with A8 extra heavy duty according to the actual operating conditions. According to the working environment, humanized design, anti-corrosion design are added and foreign advanced technologies are absorbed and optimized.
