Articulated Jib Crane

Jib crane series

  • Maximum load capacity: 320 kg
  • Maximum working radius: 4,000 mm
  • Maximum lifting speed: 0.6 m/s
  • Control: Electronic
  • Power supply: 110/230V AC, 50/60 Hz
  • Maximum power consumption: 700W
  • Protection rating: IP54
  • Operating temperature: 0°C to 40°C
  • Noise level: 40 dB(A)
Applications:

Manufacturing, automotive, warehousing, etc

Leave Message Chat Online

  • Description
  • Parameter
  • Features
  • Advantages

Description

Articulated jib crane, also known as an articulated arm crane or knuckle jib crane, is a type of material handling equipment designed for lifting and moving objects within a specific working area. The primary feature that distinguishes it from a standard jib crane is its multi-segmented arm with one or more pivot points, allowing for greater flexibility and maneuverability. Articulated jib cranes are commonly used in various industries, including manufacturing, automotive, and warehousing.

Parameter

Articulated Jib Crane Design

Model KN80  KN150  KN300  KN600
Maximum lifting weight (load and tool) 80kg 150kg 300kg 600kg
Maximum lifting speed with no-load 60 (M/min) 30(M/min) 15 (M/min) 7.5 (M/min)
Maximum lifting speed with full load 40 (M/min) 24 (M/min) 13 (M/min) 6.5 (M/min)
Maximum lifting speed in a floating mode 30 (M/min) 20 (M/min) 11 (M/min) 5.5 (M/min)
Maximum lifting range 3.5 (M) 3.5 (M) 3.5 (M) 1.75 (M)
Standards rise stroke 2.5 (M) 2.5 (M) 2.5 (M) 1.25 (M)

Features

  • Vertical support column: This is the primary support structure, which is usually anchored to the floor or a foundation. It can also be wall-mounted or attached to another structure.
  • Articulated arm: The arm consists of two or more segments connected by pivot points or joints, enabling the arm to bend at different angles. This provides increased flexibility and allows the arm to navigate around obstacles in the work area.
  • Trolley hoist or chain hoist: The hoist is mounted on the outermost segment of the articulated arm and is used for lifting, lowering, and moving loads. The hoist can be manual, electric, or pneumatic, depending on the application and required lifting capacity.
  • Rotation: The base of the articulated jib crane allows for rotation, typically ranging from 180 to 360 degrees, depending on the design and workspace constraints.

Advantages

Enhanced maneuverability: The articulated arm can navigate around obstacles, making it ideal for use in confined spaces or areas with limited clearance.

Improved ergonomics: The flexibility of the articulated arm can reduce the physical strain on workers when moving loads, leading to increased productivity and reduced risk of injury.

Customizable: Articulated jib cranes can be designed with different arm lengths, lifting capacities, and power sources to suit specific application requirements.
