5 Ton Trackless Small Gantry Crane Delivery to Australia

What Is a Trackless Small Gantry Crane?

Trackless small gantry cranes, also called rubber‑tired gantry units, are mobile lifting machines that require no fixed running rails.Rather than relying on ground‑embedded tracks, they move freely on wheels over flat, solid ground.This removes expensive rail construction work and lets you shift the crane around whenever your production workflow changes.

Our Kinocranes TGC‑5T‑4.5M model brings this flexible mobility together with solid performance: a 5‑ton lifting capacity and 4.5‑meter span.It works perfectly for workshops, small yards and production areas where space limits and budget control are key practical factors.

Project Overview

Kinocranes has completed delivery of a TGC-5T-4.5M trackless small gantry crane to a trading company in Australia. This unit comes with a 5ton working capacity, 4.5meter span, and uses an electric wormgear lifting system paired with an electric chain hoist.

Small gantry cranes suit workshops and warehouses that cannot install overhead bridge cranes because of building structure limits, or where users need mobile lifting solutions for flexible operation.

Technical Specifications

Model	TGC-5T-4.5M
Equipment Type	Trackless Gantry Crane
Rated Capacity	5 Ton
Span	4.5 meters
Lifting Height	3-4.5 meters
Lifting Mechanism	Electric Worm Gear
Hoist Type	Electric Chain Hoist
Hoisting Speed	2.8 m/min
Trolley Travel Speed	11 m/min
Power Supply	415V, 50Hz, 3-Phase
Control Mode	Pendant Control

Trackless Design Characteristics

The trackless gantry crane operates on rubber tires without fixed rail infrastructure. With this setup, you no longer need to install embedded tracks, and the whole unit can be moved around to match your actual working needs.

It runs on two 0.8 kW steering motors plus two 0.8 kW travel motors, moving smoothly over flat solid ground.This makes it ideal for workshops, small yards and production areas where flexible equipment movement is essential for daily workflows.

System Components

• Electric Worm Gear Lifting: The worm gear mechanism provides load-holding capability without the requirement for continuous brake application. Unlike hydraulic systems, the electric design eliminates fluid leakage risks and reduces maintenance requirements for indoor workshop environments.
• Electric Chain Hoist: The chain hoist configuration delivers vertical lifting at 2.8 m/min. Chain hoist construction provides durability and service access advantages compared to wire rope alternatives in daily industrial applications.
• Power System:Built around 415V, 50Hz, 3‑phase power, this unit fully meets Australian industrial standards.It can connect straight to existing on‑site power setup with no extra adjustments needed.
• Control Interface: Pendant control enables operator positioning at ground level with direct load visibility during lifting operations.

Why Choose Kinocranes?

Kinocranes is a professional crane manufacturer with extensive experience in exporting lifting equipment to Australia and the broader Asia-Pacific region. Our services include professional parameter recommendation based on your specific application, factory inspection support for quality assurance, competitive pricing with transparent cost structures, and long-term cooperation support for repeat orders and spare parts.

Every crane is customized to meet the customer's exact requirements, from capacity and span to power supply configuration and control mode.

Get a Quote for Your 5 Ton Small Gantry Crane

Whether you are a trading company, workshop operator, or industrial distributor in Australia, Kinocranes can provide a tailored small gantry crane solution that meets your lifting needs and budget. Contact us today to discuss your project requirements and receive a competitive quotation.
